ARTIZE FAUCET  |  SKU: ALA-CHR-509897  |  Code: 65147

CONCEALED BODY OF THERMOSTATIC SHOWER MIXER WITH 5-WAY DIVERTER (WITHOUT EXPOSED PARTS) - ARTIZE FAUCET - (CHROME - ALLIED - 0x15 mm - 0inchX0.6inch)

₹ 32,912  ₹ 37,400 / Pcs
Tax included

Measurable Sale of Unit: Pcs

Visual : https://webapplication.tilesdisplay.in/frontend/login-with/api/eyJpdiI6IlNHZ2NTRFFTMlVlTnN5WHk1bE5uVlE9PSIsInZhbHVlIjoiYzBnV3QxQXAyU1dIZmJYYmQ0d2tyQT09IiwibWFjIjoiZDRjYjY3MjY5Zjg2ZDkxZGU2M2Y3MDA1NjIzMGQ0ZTNmNzRkYTQzYTNjNWU2MWI3NjA5YWQ4MDBlN2Q1NGRmZSJ9?width=444&height=484&matt=0&path=https://www.chabsons.com/cdn/shop/files/VIC-CHR-503065C-444x484.jpg?v=1771045476   https://webapplication.tilesdisplay.in/frontend/login-with/api/eyJpdiI6IlNHZ2NTRFFTMlVlTnN5WHk1bE5uVlE9PSIsInZhbHVlIjoiYzBnV3QxQXAyU1dIZmJYYmQ0d2tyQT09IiwibWFjIjoiZDRjYjY3MjY5Zjg2ZDkxZGU2M2Y3MDA1NjIzMGQ0ZTNmNzRkYTQzYTNjNWU2MWI3NjA5YWQ4MDBlN2Q1NGRmZSJ9?width=444&height=484&matt=0&path=https://www.chabsons.com/cdn/shop/files/VIC-CHR-503065C-444x484.jpg?v=1771045476
Estimated Shipping Date - Sunday, 29 Mar 2026

Specification & Features
  • Product Type: Concealed body of thermostatic shower mixer with 5-way diverter (without exposed parts).
  • Flow Rate: Approximately 45.40 LPM @ 3 bar.
  • Recommended Water Pressure: 1.0 Bar – 5 Bar.
  • Material Composition: Brass ingots and brass rod as per IS quality standards.
  • Cartridge Specification: High-performance thermostatic polymer with minimized lime-scale build-up, temperature range 15 °C – 60 °C (59-104°F), ceramic diverting cartridge for five outlets, protected against backflow.
  • Water Tightness Test: Passes up to 16 bar.
  • Pressure Resistance Test: Passes up to 25 bar.
  • Finish: Chrome (CHR) plated finish.
  • Installation: Concealed / In-wall installation (exposed trims not included).

Care information
  • Wipe the chrome finish gently with a soft, damp cloth to remove water spots and dust.
  • After cleaning, dry the surface with a soft, dry cloth to protect the finish.
  • Avoid using harsh chemicals, abrasive cleaners, or acidic solutions that can damage the plating.
  • Do not scrub with steel wool, rough pads, or wire brushes to prevent surface scratches.
  • Regularly check concealed connections and service the cartridge periodically if required for optimal performance.

Description

The Artize Concealed Body of Thermostatic Shower Mixer ALA-CHR-509897 is an in-wall plumbing unit designed with a 5-way diverter to control multiple shower outlets without exposed parts. Built from premium brass with high-performance thermostatic polymer cartridges for accurate temperature control and lime-scale resistance. Perfect for modern bathroom installations requiring a concealed mixer solution.

  • Color - CHROME
  • Over all size in inches - 0inchX0.5inch
  • Over all size in mm - 0x15 mm
  • Design / Model - ALLIED
